How to Connect Oracle 19c Database in WebLogic Docker Using JSP

Learn how to connect an Oracle 19c Database to a WebLogic Docker container using JSP. This guide covers setting up your environment, creating a JSP Hello World, configuring database connections, and deploying the WAR file to WebLogic for dynamic database interaction.

Tutorial Steps

Step 1 – Download Oracle JDBC Driver Step 2 – Set Up Your Development Environment Step 3 – Create a Simple JSP Hello World Step 4 – Set Up the Project for Oracle Database Connection Step 5 – Implement the JSP Code for Database Connection Step 6 – Connect Oracle 19c and WebLogic to the Same Network Step 7 – Generate WAR File Step 8 – Deploy the JSP Project to WebLogic

Download Tutorial

Tutorial PDF Tutorial DOC

Have a Question?

+880 1687 222 000

mail@weblogic.run

Step 1 – Download Oracle JDBC Driver

To connect to an Oracle database from a JSP page, you need to download the latest Oracle JDBC driver. Follow the steps below:

Go to the Oracle JDBC Downloads page.
Download the latest ojdbc11.jar file.
Accept the license agreement to start the download.

Step 2 – Set Up Your Development Environment

For this tutorial, we'll use IntelliJ IDEA to create and run a JSP project:

Open IntelliJ IDEA and create a new project.
Select Java and then choose the Web Application template.
Click Next to proceed to the next page.
Under Dependencies, go to the Specifications section and select Full Platform. Click Next.
Choose a suitable name and location for your project and click Finish.
After the project is created, go to the Edit Configurations in the top menu.
Click the + icon to add a new configuration and select Tomcat Server > Local.
In the Tomcat Server configuration window, click on Configure to set up a new Tomcat server installation directory if not already configured.
Under the Deployment tab, click the + button to add an artifact.
Select the Artifact type you want to deploy, usually the war:exploded version of your project, and click OK.
Click Apply and then OK to save the configuration.

Step 3 – Create a Simple JSP Hello World

Before implementing the database connection, let's ensure our JSP setup works by creating a simple Hello World page:

Open index.jsp and replace the content with the following code:


<html>
  <body>
    <h2>Hello World!</h2>
  </body>
</html>

Run your project to ensure everything is set up correctly.

Step 4 – Set Up the Project for Oracle Database Connection

To connect to the Oracle 19c database, follow these steps:

Create a folder named lib inside the WEB-INF directory of your project.
Copy the downloaded ojdbc11.jar file into this lib folder.
In IntelliJ IDEA, right-click on your project and select Open Module Settings.
From Dependencies, click the + button, select 1 JARs or Directories.. and add the ojdbc11.jar file from your WEB-INF/lib folder.
Click Apply and then OK.

Step 5 – Implement the JSP Code for Database Connection

Now, let's use the provided JSP code to connect to the Oracle 19c database:

<!DOCTYPE html>
<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<%@ page import="java.sql.*" %>
<html lang="en">
  <head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>Oracle HR Database</title>
    <!-- Bootstrap 5 CSS -->
    <link href="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/css/bootstrap.min.css" rel="stylesheet">
    <link href="https://cdn.jsdelivr.net/npm/bootstrap-icons@1.10.5/font/bootstrap-icons.css" rel="stylesheet">
  </head>
  <body>
    <div class="container mt-5">
      <h2 class="text-center mb-4">Data from Oracle HR Database</h2>
      <div class="card">
        <div class="card-body">
          <div class="table-responsive">
            <table class="table table-bordered table-hover">
              <thead class="table-dark">
                <tr>
                  <th>EMPLOYEE_ID</th>
                  <th>FIRST_NAME</th>
                  <th>LAST_NAME</th>
                  <th>PHONE_NUMBER</th>
                  <th>HIRE_DATE</th>
                  <th>SALARY</th>
                  <th>Details</th>
                </tr>
              </thead>
              <tbody>
                <%
                  // JDBC connection parameters
                  String url = "jdbc:oracle:thin:@oracle19c/orclpdb1"; // Replace with your database URL. Replace oracle19c with your weblogic docker name or for a remote server, use server ip address .
                  String username = "hr"; // replace with your username
                  String password = "hr"; // replace with your password
                  Connection conn = null;
                  Statement stmt = null;
                  ResultSet rs = null;
                  try {
                    // Load Oracle JDBC Driver
                    Class.forName("oracle.jdbc.driver.OracleDriver");
                    // Establish connection
                    conn = DriverManager.getConnection(url, username, password);
                    // Create a statement
                    stmt = conn.createStatement();
                    // Execute a query
                    String query = "SELECT * FROM EMPLOYEES"; // replace with your table name
                    rs = stmt.executeQuery(query);
                    // Process the result set
                    while (rs.next()) {
                      int employeeId = rs.getInt("EMPLOYEE_ID");
                      String firstName = rs.getString("FIRST_NAME");
                      String lastName = rs.getString("LAST_NAME");
                      String phoneNumber = rs.getString("PHONE_NUMBER");
                      Date hireDate = rs.getDate("HIRE_DATE");
                      double salary = rs.getDouble("SALARY");
                      out.println("<tr>");
                      out.println("<td>" + employeeId + "</td>");
                      out.println("<td>" + firstName + "</td>");
                      out.println("<td>" + lastName + "</td>");
                      out.println("<td>" + phoneNumber + "</td>");
                      out.println("<td>" + hireDate + "</td>");
                      out.println("<td>$" + salary + "</td>");
                      out.println("<td><button type='button' class='btn btn-primary' data-bs-toggle='modal' data-bs-target='#detailsModal" + employeeId + "'>");
                      out.println("<i class='bi bi-info-circle'></i> Details</button></td>");
                      out.println("</tr>");
                      // Modal for details
                      out.println("<div class='modal fade' id='detailsModal" + employeeId + "' tabindex='-1' aria-labelledby='detailsModalLabel" + employeeId + "' aria-hidden='true'>");
                      out.println("<div class='modal-dialog modal-dialog-centered'>");
                      out.println("<div class='modal-content'>");
                      out.println("<div class='modal-header'>");
                      out.println("<h5 class='modal-title' id='detailsModalLabel" + employeeId + "'>Employee Details</h5>");
                      out.println("<button type='button' class='btn-close' data-bs-dismiss='modal' aria-label='Close'></button>");
                      out.println("</div>");
                      out.println("<div class='modal-body'>");
                      out.println("<p><strong>Employee ID:</strong> " + employeeId + "</p>");
                      out.println("<p><strong>First Name:</strong> " + firstName + "</p>");
                      out.println("<p><strong>Last Name:</strong> " + lastName + "</p>");
                      out.println("<p><strong>Phone Number:</strong> " + phoneNumber + "</p>");
                      out.println("<p><strong>Hire Date:</strong> " + hireDate + "</p>");
                      out.println("<p><strong>Salary:</strong> $" + salary + "</p>");
                      out.println("</div>");
                      out.println("<div class='modal-footer'>");
                      out.println("<button type='button' class='btn btn-secondary' data-bs-dismiss='modal'>Close</button>");
                      out.println("</div>");
                      out.println("</div>");
                      out.println("</div>");
                      out.println("</div>");
                    }
                  } catch (Exception e) {
                    e.printStackTrace();
                  } finally {
                    if (rs != null) try { rs.close(); } catch (SQLException e) { e.printStackTrace(); }
                    if (stmt != null) try { stmt.close(); } catch (SQLException e) { e.printStackTrace(); }
                    if (conn != null) try { conn.close(); } catch (SQLException e) { e.printStackTrace(); }
                  }
                %>
              </tbody>
            </table>
          </div>
        </div>
      </div>
    </div>
    <!-- Bootstrap 5 JS -->
    <script src="https://cdn.jsdelivr.net/npm/bootstrap@5.3.3/dist/js/bootstrap.bundle.min.js"></script>
  </body>
</html>

Step 6 – Connect Oracle 19c and WebLogic to the Same Network

If you are using docker in the same server/network, make sure Oracle 19c and WebLogic are on the same network. The following commands will create a docker network named oracle-network. Then connect oracle19c and weblogic docker to the oracle-network docker. Use docker names as you have, you can check it with docker ps command. Execute the following commands in your terminal:


docker network create oracle-network
docker network connect oracle-network oracle19c
docker network connect oracle-network weblogic

Step 7 – Generate WAR File

If you have used Maven, click on the Maven icon from the right side of IntelliJ Idea and expand YourProject > Lifecycle and then package

In your project directory, you will find a package directory containing your required .war file.

If you have used Gradle, click on the Gradle icon from the right side of IntelliJ Idea and expand YourProject > Task > build and then war

In your project directory, you will find your required .war file at build > libs location.

Step 8 – Deploy the JSP Project to WebLogic

To deploy your project to WebLogic, you can follow our WebLogic Deployment Tutorial.
